Noel Solder Wire Roll (Good Quality)

Noel solder wire 60/40 (Sn/Pb) has good solderability, insulation resistance, No spattering, and is non-corrosive. Its composition is 60/40 of Tin (Sn) and Lead (Pb) respectively. Noel Solder wire is widely used in electrical and electronics, solder parts like a circuit board, electronics devices, and others.

Rosin Mildly Activated (RMA) / No Clean (NC) can be used for General Purpose Soldering in Electrical & Electronics industries.

Instant Wetting Behaviour
High mobility, fast-spreading action of this flux result in more reliable Production line Soldering.
Rosin Core Solder
Minimum Resistance
Excellent manufacturing consistency and uniform quality
No Additional Flux or paste is required
No Dry Solder
Creates Less smoke and Odour
Low Melting Point
Clear residue, resulting in excellent Joint Aesthetics after Soldering.

Noel solder wire 60/40 is useful for all electronic general-purpose.

Noel solder wire 60/40 contain an optimum balance of Rosin and Activators. The alloys used for Multicore Solder wire conform to the purity requirements of the common national and international standards.

A wide range of wire diameters are manufactured to close dimensional tolerances. These start from SWG 12, 14, 16, 18, 20, 21, 22 and 24.

Solder Wire Guage (SWG)	Millimeter (mm)	Melting Point	Effect of Corrosion	Color
SWG 12	2.642	183’c- to 190’C	Non- Corrosive	Silver
SWG 14	2.032	183’c- to 190’C	Non- Corrosive	Silver
SWG 16	1.626	183’c- to 190’C	Non- Corrosive	Silver
SWG 18	1.422	183’c- to 190’C	Non- Corrosive	Silver
SWG 20	0.914	183’c- to 190’C	Non- Corrosive	Silver
SWG 21	0.813	183’c- to 190’C	Non- Corrosive	Silver
SWG 22	0.711	183’c- to 190’C	Non- Corrosive	Silver
SWG 24	0.559	183’c- to 190’C	Non- Corrosive	Silver

An optimum Temperature and controlled heating is required while doing efficient soldering. Excess Heating should be avoided while using 60/40 Solder wire.

Brand: NOEL

Pack Sizes: 10gm, 40gm, 50gm, 100gm, 250gm, 500gm

Cleaning:

Solder wire 60/40 cored Solder wires have been formulated in such a way that very bare minimum flux residue comes while soldering. In most of the electronic, and electrical applications, cleaning will not be required. Hence, 60/40 Solder wire may therefore be used to compliment a NO- CLEAN Soldering or Reflow process or to allow repairs without need for a second cleaning process.

Storage & Shelf Life

Always try to store Solder wire 60/40 in a dry and cool place. Solder wire 60/40 is classified as a non-shelf item, hence no expiry date is to be printed on the labels of solder wire.

However, we recommend for optimum performance use the product within 2 years from the date of manufacture.

* Product Images are shown for illustrative purposes only and may differ from the actual product.
