Automatic UV (Ultra violet) Ray Detection Sensor Modules

UV-Ultraviolet Ray Detection Sensor Modules are designed to measure ultraviolet (UV) radiation intensity in the environment. These sensors are widely used in weather monitoring, industrial safety, UV index measurement, flame detection, and medical applications. They can detect different UV wavelength ranges, from UVA (320–400nm) to UVB (280–320nm) and UVC (100–280nm), depending on the module type.

Common Variants and Technical Specifications:

1. GUVA-S12SD UV Sensor Module

UV Wavelength Range: 240nm – 370nm
Operating Voltage: 3.3V – 5V DC
Output Type: Analog voltage
Response Time: <500ms
Sensitivity: 0.13µA/mW/cm²
Dimensions: ~20mm x 15mm
Applications: UV index measurement, environmental monitoring, wearable UV detection

2. ML8511 UV Sensor Module

UV Wavelength Range: 280nm – 390nm
Operating Voltage: 3.3V – 5V DC
Output Type: Analog voltage
Sensitivity: ~0.15V/mW/cm²
Response Time: <500ms
Dimensions: ~21mm x 17mm
Applications: Smart UV monitoring, wearable UV meters, IoT weather stations

3. UVM-30A UV Sensor Module

UV Wavelength Range: 200nm – 370nm
Operating Voltage: 3.3V – 5V DC
Output Type: Analog voltage
Response Time: <500ms
Sensitivity: 0.1µA/mW/cm²
Dimensions: 25mm x 20mm
Applications: Solar radiation detection, industrial UV exposure control

4. VEML6075 Digital UV Sensor Module

UV Wavelength Range: UVA (320nm – 400nm), UVB (280nm – 320nm)
Operating Voltage: 3.3V – 5V DC
Output Type: I2C digital output
Response Time: <100ms
UV Index Calculation: Built-in calibration for UVA/UVB index
Dimensions: 15mm x 12mm
Applications: Wearable UV index sensors, UV skin exposure monitoring

5. SI1145 UV and Ambient Light Sensor Module

UV Wavelength Range: ~280nm – 400nm (Calculated UV index)
Operating Voltage: 3.3V – 5V DC
Output Type: I2C digital output
Additional Features: Measures visible and infrared light
Response Time: <100ms
Dimensions: 15mm x 12mm
Applications: Weather stations, IoT UV monitoring, wearable health devices

Key Features:

Accurate UV Radiation Measurement: Detects UVA, UVB, and some models estimate UVC exposure.
Analog & Digital Output Options: Compatible with microcontrollers like Arduino, ESP32, and Raspberry Pi.
Fast Response Time: Real-time UV intensity monitoring.
Compact & Low Power: Ideal for battery-powered applications.
Wide Application Range: Suitable for IoT, industrial, and health applications.

Applications:

UV Index Monitoring for Weather Stations
Industrial UV Exposure Control
Smart Wearables & UV Health Monitoring
Flame Detection Systems
Solar Radiation Measurement
