High Voltage Step-Up Power Module 20KV / 400KV / 1000KV / Boost Generator
The High Voltage Generator Step-Up Power Module is a compact DC boost converter designed to generate extremely high voltage output from a low-voltage 3–6V DC input. Commonly used for educational demonstrations, ignition experiments, and high-voltage pulse projects, this module works on a Tesla coil step-up principle.
Available in multiple output variants, including 400KV, 1000KV (1 Million Volt Impulse Module), and 20KV pulse arc generator, this module delivers powerful high-frequency arcs for experimental and demonstration purposes.
Warning: High Voltage – For Educational & Experimental Use Only. Handle With Extreme Care.
Key Features
• Low voltage 3–6V DC input
• High voltage arc output
• Compact and lightweight design
• High-quality silicone-insulated wires
• Tesla coil step-up principle
• Easy to connect and use
• Suitable for experimental applications
• High-frequency arc discharge
• Supports lithium battery input (3.7V)
• Durable insulated housing
Technical Specifications
| Parameter | 400KV Module | 1000KV Module | 20KV Pulse Module |
|---|---|---|---|
| Input Voltage | 3V – 6V DC | 3.3V – 5V DC | 3.6V – 6V DC |
| Max Output Voltage | Up to 400KV | Up to 1000KV | 20KV |
| Max Operating Current | Not Specified | 2 – 5A | Depends on Input Source |
| Output Current | Low Current HV | 0.5A | Pulse Output |
| Discharge Time | Short Arc Output | 10 Seconds | Up to 20 Seconds |
| Working Principle | Tesla Coil Boost | Tesla Coil Boost | Pulse Arc Generator |
| Power Source | 3–6V DC | 3–5V DC | 3.7V Li-ion (18650 Recommended) |
| Wire Type | Silicone Insulated | Silicone Insulated | Silicone Insulated |
Applications
• Electrical experiments
• High voltage demonstrations
• Ignition systems
• Science project kits
• Arc generation studies
• Tesla coil experiments
• DIY electronic testing
• Educational lab setups
• Combustion ignition testing
• STEM electrical learning
Precautions
⚠️ High voltage can cause serious injury.
• Do not touch output terminals during operation
• Keep away from children
• Use insulated gloves when testing
• Do not operate near flammable gases
• Do not exceed recommended input voltage
• Allow cooling between discharge cycles
• Use in dry environment only
• Not intended for continuous operation
