Essential 4000 Series Logic IC Set for Counters, Timers & Display Drivers
Note: Brand Name, Text Printed on ICs may differ from the images shown. Brand may vary in each lot.
The 4000-Series CMOS Logic ICs are widely used in digital electronics, timing circuits, counters, and display applications. This listing combines some of the most commonly used ICs: CD4047, CD4060, CD4017, CD4511,CD4051 etc, making it ideal for students, hobbyists, and circuit designers.
These ICs operate on a wide voltage range (3V–15V) and offer low power consumption, high noise immunity, and easy interfacing, making them suitable for both breadboard prototyping and production circuits.
Each IC serves a specific function in digital systems—from clock generation to counting and display driving.
Key Features
- Popular 4000 Series CMOS Logic IC family.
- Low power CMOS technology.
- Wide operating voltage range.
- High noise immunity.
- Through-hole DIP package for easy prototyping.
- Ideal for breadboards and PCB assembly.
- Suitable for digital logic and timing circuits.
- Reliable and stable operation.
- Easy interfacing with microcontrollers.
- Perfect for educational, DIY, and industrial projects.
- Available in multiple functional variants.
- Long operational life.
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | 4000 Series CMOS Logic IC |
| IC Family | 4000 Series CMOS |
| Package Type | DIP (Dual Inline Package) |
| Technology | CMOS |
| Operating Voltage | 3V–15V (Typical) |
| Maximum Operating Voltage | Up to 20V (Device Dependent) |
| Power Consumption | Low |
| Noise Immunity | High |
| Mounting Type | Through Hole |
| Operating Temperature | Device Dependent |
| Applications | Logic, Timing, Counting & Display Control |
Applications
- Digital Logic Circuits
- Timer Circuits
- Frequency Dividers
- Oscillator Circuits
- Counter Circuits
- LED Display Drivers
- Seven Segment Displays
- Multiplexer Applications
- Digital Clocks
- Event Counters
- Arduino Projects
- Embedded Systems
- Industrial Automation
- Educational Trainer Kits
- DIY Electronics Projects
- PCB Prototyping
- Robotics Projects
Precautions
- Observe correct IC orientation before installation.
- Handle the IC using proper ESD protection.
- Do not exceed the recommended operating voltage.
- Avoid reverse power connections.
- Store in anti-static packaging when not in use.
- Ensure proper soldering temperature during installation.
- Verify pin configuration from the datasheet before use.
- Keep away from moisture and static discharge.
