8 Bit Red and Blue LED Indicator Module for 3.3V and 5V Systems
The 8 Bit Red/Blue LED Indicator Module is a precise and reliable visual display solution designed for digital electronics and embedded systems. Supporting both 3.3V and 5V logic levels, this indicator module is suitable for a wide range of microcontroller and development board applications.
Available in red and blue LED variants with common anode or common cathode configurations, this module offers flexibility and ease of integration into existing circuits. Its clear, visually distinct LED output makes it ideal for status indication, signal monitoring, and bar graph displays. Whether you are an engineer, hobbyist, or student, this LED indicator module enhances project visibility and functionality with dependable performance.
Key Features:
-
8-bit LED indicator module for clear visual output
-
Available in red and blue LED colours
-
Comes in both common anode and common cathode configurations.
-
Compatible with 3.3V and 5V power systems
-
Bright, easily visible LED display
-
Compact design for easy PCB integration
-
Ideal for professional, educational, and DIY projects
Technical Specifications:
| Parameter | Details |
|---|---|
| LED Type | 8 Bit LED Indicator |
| LED Colors | Red / Blue |
| Configuration | Common Anode / Common Cathode |
| Operating Voltage | 3.3V / 5V |
| Display Format | Discrete LED Array |
| Logic Compatibility | TTL / CMOS |
| Mounting Type | PCB Mount |
| Application Type | Visual indication |
Applications:
-
Arduino and microcontroller projects
-
Status and fault indication panels
-
LED bar graph displays
-
Digital signal monitoring
-
Educational electronics kits
-
Embedded system debugging
Precautions:
-
Use appropriate current-limiting resistors
-
Do not exceed rated voltage levels
-
Confirm correct anode/cathode configuration before use
-
Avoid exposure to moisture and excessive heat
-
Handle LEDs carefully to prevent damage
