Description
Arduino Nano Every – Compact 5V Microcontroller Board with ATMega4809
The Arduino Nano Every is a compact, affordable 5V microcontroller board powered by the ATMega4809, offering more memory and performance than the classic Nano. It features 48KB Flash, 6KB SRAM, and runs at 20MHz, making it ideal for wearables, robotics, and embedded projects. With options for headers or bare-board integration, it supports 8 analog inputs, 5 PWM outputs, and full compatibility with Arduino IDE. Designed to be cost-effective and space-saving, it's perfect for both individual makers and bulk classroom kits.
Key Specifications:
-
Microcontroller: ATMega4809
-
Operating Voltage: 5V
-
Clock Speed: 20MHz
-
Memory: 48KB Flash, 6KB SRAM, 256B EEPROM
-
I/O: 14 Digital, 8 Analog, 5 PWM
-
Interfaces: UART, SPI, I2C
-
Size: 45mm x 18mm
-
Power Input (VIN): 7–21V
-
Weight: 5g (with headers)
-
USB Controller: ATSAMD11D14A
