FM Stereo Radio Module RRD-102 V2.0 Wireless Pro for Arduino Tuner RDA5807M

RDA5807M FM Stereo Radio Module is (FM Stereo radio Module) high sensitivity, low power consumption, ultra-small size of the FM stereo radio module. Using RDA Microelectronics of RDA5807M(or RDA5802NM), this circuit has fewer external components, the noise factor is minimal. Small size, low power consumption, low cost, simple application, the use of a wide range of advantages. It is an easy-to-use and possessed a highly cost-effective single-chip FM stereo radio module.

1. Move DVD, TV, MP3, MP4 and other built-in FM wide-band wireless receiver module.
2. Mining, business, campus, residential, tourist areas and other public places, stereo FM radio system.
3. Wireless audio and wireless stereo headset functionality.
4. GPS navigation, TV broadcasting systems, and other wireless FM radio.
5. High-end game consoles and wireless audio electronic toys.
6. Mobile phones, mobile phones, intercom systems, mobile radio devices and other stereo radio.
7. PDAs and Notebook PC and other peripheral applications.

Features :

1. CMOS single-chip fully-integrated FM tuner
2. Low power consumption
3. Support worldwide frequency band
4. Support RDS/RBDS
5. Digital low-IF tuner
6. Image-reject down-converter
7. High-performance A/D converter
8. IF selectivity is performed internally
9. Fully integrated digital frequency synthesizer
10. Fully integrated on-chip RF and IF VCO.
11. Only support 2-wire bus interface
12. A fully integrated on-chip loop filter
13. Autonomous search tuning
14. Support 32.768KHz crystal oscillator
15. Digital auto gain control (AGC)
16. Digital adaptive noise cancellation
17. Mono/stereo switch
18. Soft Mute
19. High cut
20. Receive signal strength indicator (RSSI) and SNR
21. Bass boost
22. Volume control and mute
23. Line-level analogue output voltage
24. Integrated LDO regulator.

Applications :

• Cellular handsets.
• Portable Radios.
• PDAs, Notebook.
• Mobile phones, mobile phones, intercom systems, mobile radio devices stereo radio.

Package Includes :

1 x RDA5807M FM Stereo Radio Module.
