U.FL IPEX to SMA Female RF Pigtail Cable Set – 10cm & 25cm Extension for Wireless Modules
The U.FL (IPEX/IPX) to SMA Female RF Pigtail Cable is a high-quality coaxial antenna extension cable designed to connect wireless modules with external SMA antennas. Manufactured using 50Ω low-loss 1.13mm RF coaxial cable, it ensures stable signal transmission with minimal attenuation, making it ideal for RF communication systems.
Available in 10cm and 25cm lengths, this pigtail cable features a miniature U.FL (IPEX/IPX) connector on one end and an SMA Female bulkhead connector on the other, allowing easy integration of WiFi, Bluetooth, ZigBee, LoRa, GSM, 3G, 4G LTE, GPS, and IoT modules with external antennas.
Its compact design makes it suitable for embedded systems, Mini PCIe WiFi cards, development boards, routers, gateways, drones, and industrial wireless communication equipment where reliable RF performance is essential.
Key Features
- U.FL (IPEX/IPX) to SMA Female RF pigtail cable.
- Low-loss 50Ω RF coaxial cable.
- High-quality 1.13mm coaxial cable.
- Excellent signal transmission with minimal loss.
- SMA Female bulkhead connector for panel mounting.
- Compact and lightweight design.
- Flexible cable for easy installation.
- Suitable for internal RF antenna connections.
- Compatible with WiFi, GPS, GSM, LTE, LoRa, ZigBee and Bluetooth modules.
- Ideal for embedded electronics and IoT projects.
- Durable connectors for reliable long-term use.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | RF Pigtail Cable |
| Connector A | U.FL (IPEX/IPX) Male |
| Connector B | SMA Female Bulkhead |
| Cable Length | 10cm / 25cm (Variant Dependent) |
| Cable Type | 1.13mm RF Coaxial Cable |
| Characteristic Impedance | 50Ω |
| Frequency Support | RF Communication Applications |
| Mounting | Bulkhead SMA Female |
| Signal Type | RF |
| Compatibility | WiFi, GSM, LTE, GPS, Bluetooth, LoRa, ZigBee Modules |
Applications
- WiFi Modules.
- Mini PCIe WiFi Cards.
- ESP32 Projects.
- Raspberry Pi Wireless Projects.
- GPS Modules.
- GSM Modules.
- 3G/4G LTE Modules.
- LoRa Devices.
- ZigBee Modules.
- Bluetooth Devices.
- IoT Gateways.
- Embedded Systems.
- Wireless Routers.
- Drone Communication Systems.
- RF Development Boards.
Precautions
- Verify connector compatibility before purchase.
- Avoid excessive bending of the RF cable.
- Ensure connectors are securely fastened during installation.
- Do not pull the cable by the connector.
- Protect connectors from dust and moisture.
- Avoid sharp cable bends to minimize signal loss.
- Handle the U.FL connector carefully during installation and removal.
- Keep away from excessive heat and mechanical stress.
