TP5100 4.2v and 8.4v Single Double Lithium Battery Charging Board

Save ₹ 11.00
SKU: 983305
1 review

Price:
Sale price₹ 59.00 Regular price₹ 70.00
( ₹ 50 without 18% GST.)

Tax included Shipping calculated at checkout

For Bulk, Call us on +91 97175 83225

Description

TP 5100 4.2v and 8.4v Dual One/Two Battery Protection Board

TP5100 4.2v 8.4v Single Double Lithium Battery Charge Management Lion Battery Compatible 2A Charging Board is a double switch buck 8.4V, single cell 4. 2V lithium battery charge management chip. Its ultra-compact QFN16 package and simple external circuit, making TP5100 ideal for portable equipment so large current charging management applications.

Meanwhile, TP5100 built-in input overcurrent, under-voltage protection, over-temperature protection, short circuit protection, battery temperature monitoring, reverse battery protection.

TP5100 has 5V-15V wide input voltage, dual battery trickle charge into pre-charge, constant current, constant voltage three-phases, pre-charge current trickle charge current through an external resistor adjustment, the maximum charge current up to 2A.

TP5100 with a frequency of 400kHz switching mode makes it possible to use a smaller outer Suo device and the large current charging still maintains a smaller amount of heat.

TP51OO built-in power PMOSFET, anti-intrusion circuit, so no anti-intrusion protection, and another external Schottky diode.

Features:

  1. Input voltage: 5-10VV DC power supply.
  2. Charge status: full and unloaded blue lights, charging red.
  3. Double 8.4v / 4.2v lithium rechargeable single .
  4. Programmable charge current. 0. 1A-2A .
  5. Programmable steady precharge current 10% -100%.
  6. Wide operating voltage, maximum reach 10V.
  7. Red and green LED charge status indicator.
  8. Chip temperature protection, overcurrent protection, under-voltage protection.
  9. Battery temperature protection, reverse battery shutdown, short circuit protection.
  10. Switching frequency 400Khz, usable inductance 20uH, and more.
  11. PWR_ON Power battery for switching control.
Model

TP5100

Input Supply voltage (V)

5 ~ 10

Programmable charge current

0.1 ~ 2 A

Length (mm)

26

Width (mm)

18

Height (mm)

5

Weight (gm)

3

Shipment Weight

0.005 kg

Shipment Dimensions

10 × 6 × 5 cm




Package Includes:

1 x  TP5100 4.2v 8.4v Single Double Lithium Battery Charging Board.
